System

  • Written in PHP (works in PHP5)
  • Fully tested on Linux, FreeBSD and Win2K
  • Should work on any other system which supports PHP
  • PHP/cron scripts for polling, analizing and consolidating data
  • Database Backend MySQL or PostgreSQL
  • Configurable Event Types and Severity Levels
  • Modular and Extensible
  • Advanced Event Filter
  • Interface & Host/Network Autodiscovery
  • Licensed under the GNU GPL

Web GUI

  • Event Console, Shows Events / Tacacs / Syslog / Alarms in the same time-ordered display
  • Map & Sub-Map support
  • Graphical Interface Traffic, Round Trip Time, Packet Loss Monitoring, and a LOT more
  • Variable Time Span in the graphs
  • Completly adminstrable via web
  • Sound Alerts in your browser
  • Events RDF/RSS Feed (for newstickers)
  • Works with SSL/HTTPS

Integration

  • Tacacs+ Authentication and Accounting
  • Syslog Logging with PCRE Matching
  • SNMP Trap Handler
  • TFTP Configuration Download and Archival (Cisco IOS & CatOS)
  • Smokeping
  • MSyslog (custom) and Syslog-NG Support
  • fping Reachability and Packet Loss
  • NTP Synchronization Verification
  • NMAP for TCP Port Discovery
  • Linux TC (traffic shapper) via custom net-snmp plugin, for TC Class Graphing
  • Linux IPTables Firewall via custom net-snmp plugin, for Firewall Packets and Traffic monitoring.

Supported SNMP MIBs & Other Monitoring

  • Interfaces (Network cards)
  • Host (Processor, Load Average)
  • Storage (Disks and Memory)
  • Applications Running (HostMIB)
  • Cisco Ping (RTT & PL on Cisco)
  • BGP4 (BGP sessions status)
  • TCP (TCP Connections, Delay)
  • Cisco MAC Accounting
  • Cisco IP Accounting
  • Cisco CSS
  • Cisco SA Agent
  • Cisco Enviormental (Temperature, Voltage, etc)
  • Cisco NAT (Number of binds and PPS)
  • Cisco PIX (Number of connections)
  • Internet Information Server (IIS) MIB
  • Livingstone PortMaster3 Serial Line MIB
  • Compaq Insight Manager MIB (Disk, Fan and Temperature)
  • Apache /server-status monitoring
  • APC UPSs
  • Alteon
  • Brocade
  • Sensors MIB (hrSensor, tested with LMSensors)
  • UPS MIB (tested with Riello)
  • Windows Informant Disk Usage

Others

  • TCP Port Content Regexp Checking (or URL)
  • Configurable per Circuit SLA’s (with RPN logic)
  • Internal Authorization Framework
  • Per Event Journals and Acknowledge
  • Triggers / Actions Framework for email/others alerts.
  • Database Abstraction Framework
  • CSV Export
  • Distributed Polling
  • Object Oriented
  • Consistent API
